Should a Fourth-Generation Tacoma Use Bilstein Coilovers or a Preload-Collar Lift?
Verify fitment with the merchant before you buy.
Reviewed by DoesItFit Editorial · How we evaluate compatibility
CHOOSE THE JOB, NOT THE LIFT NUMBER
Choose a preload-collar lift when a compatible kit lets you retain factory shocks and you primarily want modest height. Choose a vehicle-specific Bilstein coilover package when you need its damping design, spring package, and ride-height adjustment—not simply a taller stance. Exact fitment varies by fourth-generation Tacoma trim and factory suspension.
Lift-choice snapshot
| Goal/configuration | Better starting path | Required check |
|---|---|---|
| Modest height while retaining compatible factory shocks | Preload-collar kit | Match trim, factory suspension and maker's stated lift. |
| Application-specific damping, spring package and adjustment | Bilstein coilover package | Confirm exact part number, trim and lift range. |
| Tacoma Limited with AVS | Do not assume either path transfers | Require explicit AVS/Limited compatibility. |
| Added constant weight is the main issue | Height alone is not the answer | Match springs and damping to measured load. |
A preload collar retains the factory shock system
Westcott's 2024–2026 Tacoma preload-collar kit is designed to use factory shocks and springs, with stated lift differing by trim. Its published Limited-with-AVS specification is 1.5 inches front and 0.75 inch rear—not the same figure it lists for several other trims. That demonstrates why the exact factory suspension matters more than a blanket "fourth-gen Tacoma" label. Review Westcott's trim-specific specifications.
A Bilstein coilover changes the damper-and-spring package
Bilstein currently lists B8 6112 front kit #47-333246 for 2024–2026 Tacoma applications. It combines 60 mm digressive-piston coilovers, matched springs, and snap-ring spring-seat adjustment with a stated 0–2.75-inch front-lift range, depending on application. Its benefits are therefore about that damper-and-spring package—not an automatic upgrade for every fourth-generation Tacoma. Review Bilstein's Tacoma-specific kit.
Do not ignore the Limited's adaptive system
Toyota identifies Adaptive Variable Suspension on the fourth-generation Limited configuration. A kit that replaces or alters factory suspension must explicitly support that configuration; otherwise, stop at verification rather than assuming a TRD Off-Road setup transfers. See Toyota's 2024 Tacoma suspension specification.
Bottom line
For a fourth-generation Tacoma, a preload collar is the narrower answer when compatible factory suspension and modest height are the goal. A Bilstein coilover is the more involved answer when its specific damping and spring package solve a real ride/load/use requirement. Verify trim, AVS status, kit part number, wheel/tire setup, and alignment before choosing either. Limited owners should also review the Toyota TRD lift-kit application boundary.
Sources & notes
- Westcott 2024–2026 Tacoma preload-collar lift, accessed 2026-09-05. Provides its trim-specific lift claims and factory-shock approach; these claims are Westcott's and are product-specific.
- Bilstein B8 6112 kit #47-333246, accessed 2026-09-05. Lists a 2024–2026 Tacoma application and its stated components/range; verify the exact trim and suspension configuration before purchase.
- Toyota 2024 Tacoma overview, accessed 2026-09-05. Establishes that the Limited can use Adaptive Variable Suspension, a material fitment variable.
